This Stainless Steel Unions Nuts is a convenient installation and disassembly of common pipe connection. It mainly consists of nut, cloud head and flat joint three parts.Send InquiryChat Now Product Details Product Introduction This Stainless Steel Unions Nuts is a convenient installation and disassembly of common pipe connection. It mainly consists of nut, cloud head and flat joint three parts. This nut has high strength, good ductility, can give full play to the strength and ductility of the reinforcement base material. In addition, our Stainless Steel Unions Nuts features strong applicability, can be used flexibly in a narrow place where the rebar is arranged densely. It is widely used In industry and in life. Advantages The Stainless Steel Unions Nuts has good strength and good resistance to corrosion and rust. It is simple to use and you need no electricity or gas for construction connection. The application of this product can help you improve working efficiency and save labor. Quick Details:
| Product Name: | Stainless steel unions nuts |
| Body Main Material: | SS304 or SS316L |
| Normal Diameter | DN10-DN150 |
| Standard: | DIN, SMS, 3A, ISO, GB etc. |
| Application: | Dairy, Beverage, Pharmaceutical, Cosmetic & Chemical Industries |
Nut
| DN | A | B | C | H |
| 10 | 19 | 38 | Rd28x1/8” | 18 |
| 15 | 25 | 44 | Rd34x1/8” | 18 |
| 20 | 31 | 54 | Rd44x1/6” | 20 |
| 25 | 36 | 63 | Rd52x1/6” | 21 |
| 32 | 42.5 | 70 | Rd58x1/6” | 21 |
| 40 | 49 | 78 | Rd65x1/6” | 21 |
| 50 | 62 | 92 | Rd78x1/6” | 22 |
| 65 | 80 | 112 | Rd95x1/6” | 25 |
| 75/3.0” | 88 | 120 | Rd104x1/6” | 26 |
| 80 | 94 | 127 | Rd110x1/4” | 29 |
| 100 | 115 | 138 | Rd130x1/4” | 31 |
| 125 | 138 | 179 | Rd160x1/4” | 35 |
| 150 | 164 | 210 | Rd190x1/4” | 40 |
| Size | A | B | C | H |
| 25 | 32 | 51 | Rd40x1/6” | 20 |
| 32 | 40.5 | 60 | Rd48x1/6” | 22 |
| 38 | 48 | 74 | Rd60x1/6” | 25 |
| 51 | 61 | 84 | Rd70x1/6” | 26 |
| 63.5 | 74 | 100 | Rd85x1/6” | 30 |
| 76 | 87 | 114 | Rd98x1/6” | 32 |
| 101.6(Max) | 117 | 154 | Rd132x1/6” | 45 |
| 101.6(Min) | 113 | 140 | Rd125x1/4” | 32 |
Blank nut
| Size | A | B | H |
| 1” | 57 | Rd44x1/6” | 20 |
| 1 1/4” | 65 | Rd52x1/6” | 20 |
| 1 1/2” | 71 | Rd58x1/6” | 20 |
| 2” | 88 | Rd72x1/6” | 22 |
| 2 1/2” | 103 | Rd88x1/6” | 24 |
| 3” | 115 | Rd100x1/6” | 25 |
| 4” | 148 | Rd130x1/4” | 31 |
Blank nut with boss
| Size | A | B | H |
| 1” | 57 | Rd44x1/6” | 27 |
| 1 1/4” | 65 | Rd52x1/6” | 27 |
| 1 1/2” | 71 | Rd58x1/6” | 27 |
| 2” | 88 | Rd72x1/6” | 27 |
| 2 1/2” | 103 | Rd88x1/6” | 31 |
| 3” | 115 | Rd100x1/6” | 32 |
| 4” | 148 | Rd130x1/4” | 38 |
Package Type: 1.) 1.1*1.1*1.1 m plywood case or suitable size 2.) Customers’ logo is available on package. 3.) More than 3 layers of carton box for packaging before load into plywood case.
